Model
JH6 28.550 FT AMT
6x4 AMT TRUCK TRACTOR
Model JH6 28.550 FT AMT
Starting at R 1,950,000
- Full Floating Extended High Roof Cab with innovative Flat Floor Design for optimal comfort
- 6 cylinder in line, water cooled, turbo charged & intercooled
- 12 Speed AMT with Intarder Transmission
- Full Air - Dual Circuit with ABS
- Front Suspension: Parabolic Leaf Springs with Double Acting Shock Absorbers
- Rear Suspension: Air Suspension
- Equipped with China's most fuel efficient engine
Discover the Highlights
Specifications
JH6 28.550 FT AMT
CAB
Cab Control
Forward Tilt Cab
Seating
Driver + 1 Passengers
Type/Extras
Sleeper Cab with Aircon, Radio with USB, Suspension seat
ENGINE
Make & Model
CA6DM3-55
Capacity
12 520 cm3
Layout & Type
6 cylinder in line, water cooled, turbo charged & intercooled
Emissions Standard
Euro III
Power @ r/min (Kw)
407 @ 1 800rpm
Torque @ r.min (Nm)
2 600 from 1 300 to 1 600rpm
TRANSMISSION
Make & Model
ZF12TX2621TD
Type
12 Speed AMT with Intarder
Forward Ratios
16.69, 12.92, 9.93, 7.67, 5.90, 4.57, 3.66, 2.83, 2.17, 1.68, 1.29, 1.00
Reverse Ratio
15.54, 12.03
CLUTCH
Diameter
430 mm
Type
Dry Type Single Plate
Operation
Air Assisted
STEERING
Gear Ratio
23:1
Type
Recirculating Ball
Operation
Hydraulic Power Steering
PERFORMANCE
Gradeability @ V
Max 30%
Permissible Road Speed
80km/h
AXLES
Front Axle
I- Beam section (Forged Steel)
Rear Axle - Gearing Type
Full Floating- Single Reduction
Rear Axle Ratio
3.077:1
BRAKES
System Type
Full Air - Dual Circuit with ABS
Park/Emergency System
Spring Brake/Rear Booster
Auxiliary Braking
Engine Brake, Intarder
FUEL TANK
Number
Two
Total Capacity
725+500 Litre
ELECTRICAL SYSTEM
System Voltage & Type
24V Negative Earth / 75 Ampere
No. of Batteries
Two X 12V
CHASSIS
Type
Straight Ladder Type - Riveted
Front Suspension
Parabolic Leaf Springs with Double Acting Shock Absorbers
Rear Suspension
Air Suspension
WHEELS
Tyre Size
315/80R22.5-20
Rim Size
9.00 X 22.5
Type
Tubeless Radial
MASS DATA
Manufacturer’s Gross Vehicle Mass (GVM)
28 000 kg
Manufacturer’s Gross Combination Mass (GCM)
62 200 kg
Manufacturer’s Front Axle Mass (GA Front)
7 000 kg
Manufacturer’s Rear Axle Mass (GAU Rear)
18 000 kg
Permissible Gross Vehicle Mass (V)
25 700 kg
Permissible Gross Combination Mass (D/T)
56 000 kg
Permissible Front Axle Mass (A Front)
7 000 kg
Permissible Rear Axle Mass (A Rear)
18 000 kg
Unladen Front Axle Mass (T Front)
5 330 kg
Unladen Rear Axle Mass (T Rear)
3 920 kg
Unladen Mass Total (Tare)
9 250 kg
DIMENSIONS
Wheelbase (WB)
3 450 mm + 1 350 mm
Overall Length (OL)
6 890 mm
Cab Length (A)
2 646 mm
Overall Width (OW)
2 500 mm
Overall Height (OH)
3 995 mm
Front Overhang (D)
1 495 mm
Rear Overhang (ROH)
745 mm
Cab to Rear Axle (CA)
4 152 mm
Minimum Turning Radius
7 500 mm
Minimum Turning Diameter
15 000 mm
Ground Clearance
222 mm
Track - Front
2 042 mm
Track - Rear
1 852 mm
Chassis Outer Width
800 mm
Chassis Inner Width
640 mm
OTHER
Refrigerator & Air
✔
Conditioner
✔
ECAS/AEBS/EBS/
✔
ESC/FCW/LDWS
✔
Jost Fifth wheel
✔
